Amiko TSC1000 Digital Meter

Amiko TSC1000 Digital Meter

Satellite locator

Real-time angle calculator

DVB S/DVBS2 DVBT/DVBT2 DVBC/DVBC2 ANALOG TV

LNB short-circuit protection and indicator.

Extremely fast and accurate with high sensitivity.

320*240 color LCD display with controllable back light.

Database editable by user easily.

Signal lock audible notification.

All DiSEqC protocal monitor based on 22KHz singal.

Database can be edited on PC and downloaded by USB port.

Ultra-long standby, low power consumption.

Fast charging Li-ion battery can last around 3 hours

Specification

DVB-T

Bit Error Rate (BER) CBER (before Viterbi): 1E-7–1E-3VBER (before Reed Solomon): 1E-7–1E-3

Frequency range 42-1005MHz

Measurement Imput level 30-100 dBμV, +/-2dB

Modulation Error Rate (MER) Measurement 5-35dB, +/-0.5dB

Bandwidth 6MHz, 7 MHz, 8 MHz

FFT type2k, 8k

Constellation QPSK, 16QAM, 64QAM

Viterbi rate1/2, 2/3, 3/4, 5/6, 7/8

Guard interval auto

Spectrum inversion auto

DVB-T2

Bit Error Rate (BER) CBER (before LDPC):1E-7–1E-3LBER (before BCH): 1E-9–1E-5

Frequency range 42-1005 MHz

Measurement Imput level 30-100 dBμV, +/-2dB

Modulation Error Rate (MER) Measurement 5-35dB, +/-0.5dB

Bandwidth 1.7MHz, 5MHz, 6MHz, 7 MHz, 8 MHz

Mode SISO, MISO, PLP single or multiple

FFT type1k, 2k, 4k, 8k, 16k, 32k + extended bandwidth

Constellation QPSK, 16QAM, 64QAM, 256QAM

Viterbi rate1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 1/3, 2/5

Guard Interval auto

Spectrum inversion auto

DVB-C

Bit Error Rate (BER) (before Reed Solomon): 1E-7–1E-3PER (Packet Error Rate): 1E-6–1E-2

Frequency range 42-1005MHz

Measurement Imput level 35-100 dBμV, +/-2dB

MER 20-40dB, +/-0.5dB

Symbol Rate1.7 to 7.2 Msym/s

Constellation 16QAM, 32QAM, 64QAM, 128QAM, 256QAM

Spectrum inversion auto

DVB-C2

Bit Error Rate (BER) CBER (before LDPC): 1E-7–1E-3LBER (before BCH): 1E-9–1E-5

Frequency range 42-1005MHz

Measurement Imput level 30-100 dBμV, +/-2dB

MER 5-35dB, +/-0.5dB
